Industrial PoE – Power over Ethernet – Switches

Power over Ethernet switches for effective, secure and reliable industrial networks

The Westermo range of industrial PoE switches are designed to meet either the 802.3af standard, or the 802.3at Power over Ethernet (PoE) Plus standard for high power applications e.g. real time IP video surveillance. With Gigabit uplink ports included with every model, the i-line range of robust industrial PoE switches ensures high-bandwidth connections for standard IP cameras whether installed on a bus, in a train, on a boat etc.

• Industrial PoE  Switches

  • PII-2G: Industrial 2-port PoE Injector, 2 x 10/100/1000 TX data in ports, 2 x 10/100/1000 TX IEEE 802.3af/at PoE ports
  • PMI-110-F2G: Managed PoE Gigabit Switch, 8 x RJ-45, 10/100 Mbit/s (8 with PoE capability), 2 x RJ-45/SFP combination port, 10/100/1000 Base-TX RJ-45 or 100/1000 Base FX LC
  • PSI-660G-24V: 4x PoE+2Gb Booster PoE Switch, 4x 10/100 TX IEEE 802.3af PoE ports plus 2x 10/100/1000TX uplink ports
  • PSI-1010G-24V: 8x PoE+2Gb Booster PoE Switch, 8x 10/100 TX IEEE 802.3af PoE ports plus 2x 10/100/1000TX uplink ports
  • Viper-112A-P8-HV: EN 50155 Managed PoE Switch – high voltage version, 12 x 100 Mbps ports, whereof 8 PoE, 1 x USB, 1 x RS-232 console port
  • Viper-112A-P8-LV: EN 50155 Managed PoE Switch – low voltage version, 12 x 100 Mbps ports, whereof 8 PoE, 1 x USB, 1 x RS-232 console port
  • Viper-112A-T3G-P8-HV: EN 50155 Managed Gbps PoE Switch, 3 x Gbps ports, 9 x 100 Mbps ports, whereof 8 PoE, 1 x USB, 1 x RS-232 console port
  • Viper-112A-T3G-P8-LV: EN 50155 Managed Gbps PoE Switch, 3 x Gbps ports, 9 x 100 Mbps ports, whereof 8 PoE, 1 x USB, 1 x RS-232 console port
  • Viper-112A-T5G-P8-HV: EN 50155 Managed Gbps PoE Switch, 5 x Gbps ports, whereof 2 PoE, 7 x 100 Mbps ports, whereof 6 PoE, 1 x USB, 1 x RS-232 console port
  • Viper-112A-T5G-P8-LV: EN 50155 Managed Gbps PoE Switch, 5 x Gbps ports, whereof 2 PoE, 7 x 100 Mbps ports, whereof 6 PoE, 1 x USB, 1 x RS-232 console port
  • Viper-120A-P8-HV: EN 50155 Managed PoE Switch, 20 x 100 Mbps ports, whereof 8 PoE, 1 x USB, 1 x RS-232 console port
  • Viper-120A-P8-LV: EN 50155 Managed PoE Switch, 20 x 100 Mbps ports, whereof 8 PoE, 1 x USB, 1 x RS-232 console port
  • Viper-120A-T4G-P8-HV: EN 50155 Managed Gbps PoE Switch, 4 x Gbps ports, whereof 2 PoE, 16 x 100 Mbps ports, whereof 6 PoE, 1 x USB, 1 x RS-232 console port
  • Viper-120A-T4G-P8-LV: EN 50155 Managed Gbps PoE Switch, 4 x Gbps ports, whereof 2 PoE, 16 x 100 Mbps ports, whereof 6 PoE, 1 x USB, 1 x RS-232 console port
  • Viper-212A-P8-HV: EN 50155 Managed PoE Routing Switch, 12 x 100 Mbps ports, whereof 8 PoE, 1 x USB, 1 x RS-232 console port
  • Viper-212A-P8-LV: EN 50155 Managed PoE Switch, 12 x 100 Mbps ports, whereof 8 PoE, 1 x USB, 1 x RS-232 console port
  • Viper-212A-T3G-P8-HV: EN 50155 Managed Gbps PoE Routing Switch, 3 x Gbps ports, 9 x 100 Mbps ports, whereof 8 PoE, 1 x USB, 1 x RS-232 console port
  • Viper-212A-T3G-P8-LV: EN 50155 Managed Gbps PoE Routing Switch, 3 x Gbps ports, 9 x 100 Mbps ports, whereof 8 PoE, 1 x USB, 1 x RS-232 console port
  • Viper-212A-T5G-P8-HV: EN 50155 Managed Gbps PoE Routing Switch, 5 x Gbps ports, whereof 2 PoE, 7 x 100 Mbps ports, whereof 6 PoE, 1 x USB, 1 x RS-232 console port
  • Viper-212A-T5G-P8-LV: EN 50155 Managed Gbps PoE Routing Switch, 5 x Gbps ports, whereof 2 PoE, 7 x 100 Mbps ports, whereof 6 PoE, 1 x USB, 1 x RS-232 console port
  • Viper-220A-P8-HV: EN 50155 Managed PoE Routing Switch, 20 x 100 Mbps ports, whereof 8 PoE, 1 x USB, 1 x RS-232 console port
  • Viper-220A-P8-LV: EN 50155 Managed PoE Routing Switch, 20 x 100 Mbps ports, whereof 8 PoE, 1 x USB, 1 x RS-232 console port
  • Viper-220A-T4G-P8-HV: EN 50155 Managed Gbps PoE Routing Switch, 4 x Gbps ports, whereof 2 PoE, 16 x 100 Mbps ports, whereof 6 PoE, 1 x USB, 1 x RS-232 console port
  • Viper-220A-T4G-P8-LV:  EN 50155 Managed Gbps PoE Routing Switch, 4 x Gbps ports, whereof 2 PoE, 16 x 100 Mbps ports, whereof 6 PoE, 1 x USB,1 x RS-232 console port

If you need more info and if you have any projects, please contact us
